Fantastisk stereo pakke !
PSB SYNCRONY
Advanced Driver Designs
The B600’s 6½" (165mm) woofer features a woven carbon fibre cone that combines low mass and high rigidity, a mass-loaded rubber surround that suppresses unwanted reflections, and an advanced motor structure assures that maintains constant magnetic force throughout the voice coil gap. The 1" (25mm) titanium dome tweeter features Ferrofluid cooling and a neodymium magnet.
Together, these refinements result in wider bandwidth, higher efficiency, better power handling, and reduced harmonic and intermodulation distortion. Combined with the B600’s amplitude-perfect Linkwitz-Riely 4th-order acoustic crossover, these advanced drivers deliver remarkably flat frequency response, so that every sound you hear is True to Nature.
Silence Please
The Synchrony B600 incorporates several measures to suppress unwanted noise and vibration. The enclosure has extensive internal bracing to minimize resonances that can cause uneven response and blur transients. The front baffle is clad in a 5mm-thick solid aluminum plate to minimize “baffle talk” that can obscure fine detail.
On the bottom of the enclosure are four isolation feet, custom designed for PSB by IsoAcoustics, that prevent vibrations from the drivers and cabinet from being reflected back into the enclosure. This translates to improved micro-detail, clearer transients, a wider soundstage, and more precise imaging.
Furniture Grade
PSB’s Synchrony B600 Premium Bookshelf Speakers are a feast for the eyes as well as the ears. Available in Satin Walnut Veneer and High Gloss Piano Black finishes, they’ll fit gracefully into any listening space. Acoustically transparent magnetically attached grilles enhance the B600’s visual appeal. PSB offers matching stands that provide a non-resonant connection to the speakers’ IsoAcoustics isolation feet.
Frequency response: 55-20,000Hz (±1.5db), 50-20,000Hz (±3db)
1 x 6½" woofer with woven carbon fibre cone, cast aluminum basket, mass-loaded rubber surround, and advanced motor structure
1 x 1" (25mm) titanium dome tweeter with Ferrofluid damping and neodymium magnet
Amplitude-perfect Linkwitz-Riley 4th-order acoustic crossover
Integrated acoustic isolators from IsoAcoustics
Low-resonance MDF cabinet with extensive bracing and decoupled aluminum-clad front baffle
Satin Walnut Veneer and High Gloss Piano Black, with acoustically transparent magnetically attached grilles
Optional custom-fitted 24" speaker stands
Related
Frequency Response
On Axis @ 0° ±3dB 50-20,000Hz
On Axis @ 0° ±1 1/2dB 55-20,000Hz
Off Axis @ 30° ±1 1/2dB 55-10,000Hz
LF Cutoff 35Hz
Sensitivity
Anechoic Chamber 86dB
Listening Room 88dB
Impedance
Nominal 6 Ohms
Minimum 4 Ohms
Input Power
Recommended 15 - 150 Watts
Program 150 Watts
Acoustic Design
Tweeter 1” (25mm) Titanium Dome with Ferrofluid
Woofer 6 1/2” (165mm)
Cast Basket
Carbon Fibre Cone
Rubber Surround
Crossover 2,200Hz, L4
Design Type 2-way system
Bass Reflex,
Rear facing port
Dimensions / Weights / Finish
Size (W x H x D) 9 x 15 1/2 x 11 1/2”
228 x 393 x 298mm
Weight Net - 23 lbs (10.4 kg)
Finish Satin Walnut
High Gloss Black
Features Dual, 5-way, Gold-plated Binding Posts
Tri-wireable/Tri-ampable,
Bi-wireable/Bi-ampable,
Magnetic Grille
isoAcoustic isolation Feet
Rear Facing Port
ROTEL RA-1572MK2
RA-1572MKII integrertforsterker bringer musikken din til live med eksepsjonell troverdighet og leverer 120, klasse AB, watt i 8 ohm med dyp, kontrollert bass. En audiofil DAC, analog, digital, aptXTM og AAC Bluetooth, PC-USB-støttende MQA og Moving Magnet Phono-inngang sikrer eksepsjonelle detaljer og et oppslukende lydbilde.
RA-1572MKII Integrertforsterker er en essensiell komponent for musikkelskere som utnytter det beste av Rotels analoge og digitale teknologier som bringer musikk til live med eksepsjonell troverdighet. Rollen til en integrert forsterker fortsetter å utvikle seg med RA-1572MKII optimalisert i alle aspekter, inkludert effektforsterkeren som leverer 120 robuste klasse AB watt i 8 ohm, lydkretsdesigninnovasjoner, førsteklasses audiofil digital til analog omformer og et komplett sett med kildeinnganger.
Som typisk for Rotel-forsterkere benytter RA-1572MKII en egenprodusert overdimensjonert ringkjernetrafo. Formen på ringkjernetrafoen bidrar til å forhindre at strålende strøy ødelegger lydsignaler når de passerer gjennom tilstøtende kretser. Transformatoren mater en bank med 4 lav ESR, høy effektivitet, T-Network spaltefolie lagringskondensatorer for dyp, kontrollert basenergi.
RA-1572MKII støtter digitale kilder ved bruk av en Texas Instruments 32-bit/384kHz DAC med kritisk innstilte utgangsfilterkretser som gir deg selv de mest subtile detaljene. Forforsterkerkretsene og de lineære forsterkertrinnene er skreddersydd for å sikre naturlige detaljer, smidighet og et oppslukende lydbilde.
Analog, digital, PC-USB-støttende MQA, aptX ™ og AAC trådløs Bluetooth-streaming, XLR balansert og MM riaa sikrer tilkobling til dine favorittkilder.
RA-1572MKII er sertifisert Roon Tested som gir den beste opplevelsen ved hjelp av Roon-programvare, slik at du bare kan nyte musikken. Frontpanelet inkluderer en statusvisning, kilde- og volumkontroll, valg av høyttaler A-B for sone 2 og 3,5 mm hodetelefonkontakt. Ethernet- og RS232 -tilkoblinger tillater sømløs integrasjon med kontrollsystemer og programvareoppdateringer.
DIMENSIONS (W × H × D) 431 × 144 × 358mm
FRONT PANEL HEIGHT 3U / 132.6mm (5.25")
POWER REQUIREMENTS 120V, 60Hz
POWER CONSUMPTION 400W
STANDBY POWER CONSUMPTION <0.5W
NET WEIGHT 13.63kg (30.05lbs.)
BTU RATING (4O, 1/8th power) 810 BTU/h
MAXIMUM POWER OUTPUT 200W/Ch (4O)
CONTINUOUS POWER OUTPUT 120W/Ch (8O)
TOTAL HARMONIC DISTORTION <0.018%
FREQUENCY RESPONSE Line Level Inputs:10Hz - 100kHz, ±0.5dBDigital Inputs:10Hz - 90kHz, ±2dBPhono Input:20Hz - 20kHz, ±0.5dB
S/N RATIO (IHF "A" Weighted) Line Level Inputs: 100dBDigital Inputs: 100dBPhono Input: 80dB
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)<0.03%
DAMPING FACTOR 300
INPUT SENSITIVITY Line Level Inputs (RCA): 270mVLine Level Inputs (XLR): 440mVDigital Inputs: 0 dBFsPhono Input (MM): 2.1mV
INPUT IMPEDANCE Line Level Inputs (RCA): 100kOLine Level Inputs (XLR): 100kODigital Inputs: 75OPhono Input (MM): 47kO
INPUT OVERLOAD Line Level Inputs (RCA): 4VLine Level Inputs (XLR): 5.5VPhono Input: 32mV
PREOUT LEVEL 1.5V
OUTPUT IMPEDANCE 470O
COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit/192kHz)
PC-USB USB Audio Class 1 (up to 24-bit/192kHz)USB Audio Class 2 (up to 32-bit/384kHz)**Driver installation requiredMQA and MQA Studio (up to 24-bit/384kHz )Roon Tested
